【Generative Model】Look-into Video-Prediction-Policy codebase

@article{hu2024video,
  title={Video Prediction Policy: A Generalist Robot Policy with Predictive Visual Representations},
  author={Hu, Yucheng and Guo, Yanjiang and Wang, Pengchao and Chen, Xiaoyu and Wang, Yen-Jen and Zhang, Jianke and Sreenath, Koushil and Lu, Chaochao and Chen, Jianyu},
  journal={arXiv preprint arXiv:2412.14803},
  year={2024}
}

class VPP_Policy(...):
	def __init__(...):
		# img encoder
		self.TVP_encoder = Diffusion_feature_extractor(pipeline=pipeline,
			tokenizer=tokenizer,
			text_encoder=text_encoder,
			position_encoding = self.use_position_encoding)
		# goal encoder
		self.language_goal = LangClip(model_name='ViT-B/32').to(self.device)
		...

	def extract_predictive_featue(self, dataset_batch):
		...
		latent_goal = self.language_goal(dataset_batch["lang"])

		with torch.no_grad():
			input_rgb = torch.cat([rgb_static, rgb_gripper], dim=0)
			language = language + language
			perceptual_features = self.TVP_encoder(input_rgb, language, self.timestep, self.extract_layer_idx, all_layer=self.use_all_layer, step_time=1, max_length=self.max_length)

			perceptual_features = self.Video_Former(perceptual_features)

			...
			return predictive_feature, latent_goal

	def training_step(self, dataset_batch):
		predictive_feature, latent_goal = self.extract_predictive_feature(dataset_batch)

		act_loss, _, _ = self.diffusion_loss(
			predictive_feature.
			latent_goal,
			dataset_batch["actions"],
		)

class VPP_Policy(pl.LightningModule):
    def __init__(
        self,
        latent_dim: int = 512,
        use_Former: str = '3d',
        extract_layer_idx: int = 1,  # Controls which layer to extract features from
        use_all_layer: bool = False,  # Option to use all layers
        action_dim: int = 7,
        action_seq_len: int = 10,
    ):

class Diffusion_feature_extractor(nn.Module):
	def forward(
		self,...
		extract_layer_idx,...
	)
		...
		for i, t in enumerate(timesteps):
			...
			feature_pred = self.step_unet(
				...
				use_layer_idx=extract_layer_idx
			)[0]
			...
		return feature_pred

class Video_Former_3D(nn.Module):
    def __init__(
        self,
        dim: int,
        depth: int,
        condition_dim: int = 1280,
        dim_head: int = 64,
        heads: int = 8,
        num_latents: int = 64,
        num_frame: int = 16,
        num_time_embeds: int = 4,
        use_temporal: bool = False,
    ):
        # ...
        self.layers = nn.ModuleList([])
        if self.use_temporal:
            for _ in range(depth):
                self.layers.append(
                    nn.ModuleList([
                        PerceiverAttentionLayer(dim=dim, dim_head=dim_head, heads=heads),
                        Attention(dim, num_heads=heads, qkv_bias=True, use_cross_attn=False,
                                y_dim=512, attn_mask=attn_mask),
                        feed_forward_layer(dim=dim, mult=ff_mult, activation=activation),
                    ])
                )

	def forward(x_f, mask): # x_f: input visual embedding
		# 1. Mask the position embeddings for the padded frames
		...
		# 2. Apply the position embeddings
		...
		x_f = x_f + time_pos_emb

		# 3. Apply attention and feed-forward layer
		for attn, temp_attn, ffw in self.layers:
			x = x + attn(x_f, x)
			x = rearrange(x, '(b T) q d -> (b q) T d', b = batch_size)
			x = x + Temp_attn(x)
			x = rearrange(x, '(b q) T d -> (b T) q d', b = batch_size)
			x = x + ffw(x)

		x = x.reshape(batch_size, -1 ,x.shape[1],x.shape[2])
		x = rearrange(x, 'b T q d -> b (T q) d')
		norm = self.norm(x)

		return norm

class PerceiverAttentionLayer(nn.Module):
	def forward(self, features, latents):
		# Layer normalization
		x = self.norm_media(features)
		latents = self.norm_latents(latents)

		# Cross-attention
		q = self.to_q(latents)
		kv_input = toch.cat((x, latents), dim=-2)
		k = self.to_k(kv_input)
		v = self.to_v(kv_input)

		# attention scores
		sim = eimsum('b h q d, b h f d -> b h q f', q, k)
		alphas = sim.softmax(dim=-1)

		out = einsum('b h q f, b h f v -> b h q v', alphas, v)
		out = rearrange(out, 'b h q v -> b q (h v)')

		return self.to_out(out)

class Attention(...):
	def forward(self, x):
		# Perform self-attention

class VPP_Policy(...):
	def diffusion_loss(
		self,
		perceptual_emb,
		latent_goal,
		actions
	):
		sigmas = self.male_sample_density()(shape=(len(actions),))
		noise = torch.rand_like(actions)
		loss = self.model.loss(perceptual_emb, actions, latent_goal, noise, sigmas)
		return loss, sigmas, noise

class GCDenoiser(nn.Module):
	def loss(self, state, action, goal, noise, sigma, **kwargs):
		c_skip, c_out, c_in = [append_dims(x, action.ndim) for x in self.get_scalings(sigma)]
		noised_input = action + noise * append_dims(sigma, action.ndim)
		model_output = self.inner_model(state, noised_input * c_in, goal, sigma, **kwargs)
		target = (action - c_skip * noised_input) / c_out # NOTE: target score
		return (model_output - target).pow(2).flatten(1).mean(), model_output

class GCDenoiser(nn.Module):
	def _init__(...):
		self.inner_model = DiffusionTransformer(
			action_dim = action_dim,
			obs_dim = obs_dim,
			goal_dim = goal_dim,
			proprio_dim= proprio_dim,
			goal_conditioned = True,
			...
		)

class DiffusionTransformer(nn.Module):
	def __init__(...):
		self.encoder = TransformerEncoder(...)
		self.decoder = TransformerFiLMDecoder(...)
		self.proprio_emb = nn.Sequential(
			nn.Linear(...)
			nn.Mish(),
			nn.Linear(...)
		)
		self.sigma_emb = ...
		self.action_emb = nn.Linear(...)
	def forward(self, states, actions, goals, signa, uncond: Optional[bool]):
		# actions: actually noises (or noised_input for training)
		context = self.forward_enc_only(states, actions, goals, sigma, uncond)
		pred_actoins = self.forward_dec_only(context, actions, sigma)
		return pred_actions

class VPP_Policy:
	def eval_forward(self, obs, goals)
	act_seq = self.denoise_actions(
		torch.zeros_like(latent_goal).to(latent_goal.device),
		perceptual_emb,
		latent_goal,
		inference=True,
	)
